FMUSER FBE200 IPTV Encoder can deliver H.264 encoding video streams with more channels of independent IP output to various servers for IPTV & OTT application, such as Adobe Flash Server(FMS), Wowza Media Server, Windows Media Server , RED5,and some other servers based on UDP / RTSP / RTMP / HTTP / HLS / ONVIF protocols. Of course it support VLC decode.
FBE200 is compatible with most of streaming platforms, Live Broadcast On Any Streaming Service like WOWZA,FMS,Red5,Youtube Live, Facebook live, Ustream, Livestream, Twitch, Meridix, Streamspot, Dacast, Tikilive, Netrmedia...
We also have SDI versions, 4 in 1 or 16 in 1 encoders in professional 19' Rack chassis, please feel free to contact us if you need them.
If you want to promote your own brand, we can also do OEM for you.
**We reserve the right to upgrade the appearance or functions of the product without extra notice.
Features
--Video Compression support H.264,Main Profile / High Profile / Baseline Profile
--Audio Compression support MP3 & AAC-LC/HE audio compression
--Bitrate CBR / VBR16Kbit/s--12Mbit/s
--Streaming resolution up to 720, 720P, 1080P
--GOP frame rate settings supported
--insertable of logo and Scroll Caption(OSD)
--Adjustable of audio gain
--Capable of image parameter settings
--Support up to 3 stream at a same time
--Switchable of audio output mode: Left, right and Stereo
--Configurable of Multi-rate, Multi-resolution, Multi-protocol
--Providing HLS / RTSP / HTTP / UDP / RTMP protocol
--Support ffmpeg , HLS
--Support ONVIF Network Video Protocol
--Web-based management
--Full-duplex mode 1000M / 100M
--support wifi connection for RTMP upload
--Multiple output streams per input service to support Broadcast, VOD, IPTV and OTT, Mobile/ web, Set top box applications
--Support multiple equipments display at the same time on one computer
--Support Microsoft standard flow driven architecture (WDM architecture), support Microsoft WMENCODER, compatible with Windows VFW software architecture and WDM mode.
Applications
--Digital TV Broadcasting System
--RJ45 Digital TV Programs Transmission
--Hotel TV System
--Head-end system of Digital TV branch network
--CATV Broadcasting system
--Edge side of Digital TV backbone network
--IPTV and OTT headend system
--Digital Signage
--Video Conference
--Replace HD Video Capture Card
--Hotel TV system
--Streaming Live Broadcast
--Teaching/Campus Broadcast
--Recording System
--NVR,Net Video Recorder
IP output over RTP / RTSP / RTMP / HTTP / HLS -- Transfer through internet or LAN
FMUSER FBE200 support a secure live and on-demand streaming both within and outside their corporate networks. Empowers enterprises to personalize engagement, reduce travel costs, extend their reach, and boost sales through video streaming.
Broadcast Streaming Solutions, Powering Leading-Edge Broadcasting.
Deliver traditional broadcast channels over the top while also creating leading-edge broadcasting channels to power mobile journalism and citizen participation.
Education Streaming Solutions.Streaming for the classroom and beyond.Extend your reach. Engage. Make the most of your budget.
IP output over UDP (Unicast / Multicast) -- Transfer trough LAN
Schematic diagram
Technical Specifications:
*VIDEO Encoding
--Video Compression: H.264 / AVC / HEVC High Profile Level 1.5
--Video Inputs: 1 x HDMI 1.3a version (support HDCP protocol, or 1 x SDI for option)
--Resolution:
-----HDMI / SDI main stream:
1920x1080, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 720x540, 720x480,
720x404, 704x576, 640x480, 640x360, auto
-----HDMI / SDI sub-stream:
1280x720, 800x450, 720x576, 720x540, 720x480, 720x404, 704x576, 640x480,
640x300, 352x288, 320x240, 320x180, auto
--Bit-rate: 16kbps~12Mbps, CBR/VBR
--Video pre-processing: Noise reduction, Sharpen, Filtering
*AUDIO Encoding
--Audio compression: AAC, MP3
--Sampling rate: Adaptive, selectable of re-sample.
--Sampling accuracy: 24-bit
--Bit Rate: 48k,64k,96k,128k,160k,192k,256k
--Re-sample:32k, 44.1k
*IP Encapsulation output
--Transport protocol: TS over IP output, RTSP / HTTP / UDP or RTMP protocol
--For each HDMI (SDI) to IP output (HTTP / RTSP / UDP / RTMP / HLS protocol) 3 group out with higher resolution(up to 1080P) for large screen application.
--Output : RJ45, 100/1000M Full
*GENERAL OPTION
--Power supply Voltage: 110VAC±10%, 50/60Hz; 220VAC±10%, 50/60Hz
--DC Power input: 12V or 5V by Micro-USB
--Consumption: less than 40W
--Operating temperature: 0--45°C (operation), -20--80°C (storage)
--Dimensions: 146mm(W)x140mm(D)x27mm(H)
--Package Dimensions: 165mm(W)x112mm(D)x70mm(H)
--Package Weight: 0.65KG
Appearance and Illustration
Front Panel:
1. RJ45 100M / 1000M IP Output
2. 3.5mm Stereo Audio Line in
3. HDMI Video in
4. Status LED / Power LED
5. Reset to Factory
Rear Panel:
1. 2.4G Wifi Antenna Port--SMA-K
2. Micro-USB power in 5V
3. DC Power in 12V
Network Management System
Network management system is applied to control and manage parameters and setting, etc. It centralizes encoders through network easy.
Packing List:
1pcs FBE200-H.264 IPTV streaming encoder HDMI in
1pcs Wifi antenna
1pcs HDMI Cable
1pcs 3.5mm to RCA female (L-R)
1pcs 110V / 220V to 12V Power supply
1pcs User Manual
Order Guide
|
Model No.
|
Chassis
|
Encoding
|
Input
|
wireless
|
other
|
|
FBE200-H.264-LAN
|
Small box
|
h.264
|
1 x HDMI or SDI in
3.5mm Stereo in
|
--
|
--
|
|
FBE200-H.264
|
Small box
|
h.264
|
1 x HDMI or SDI in
3.5mm Stereo in
|
2.4g wifi
|
HLS
|
|
FBE200-H.265
|
Small box
|
h.264 / h.265
|
1 x HDMI or SDI in
3.5mm Stereo in
|
2.4g wifi
|
HLS
|
|
FBE204-H.264
|
19’ 1U Rack
|
h.264
|
4 x HDMI or SDI in
3.5mm Stereo in
|
--
|
--
|
|
FBE204-H.265
|
19’ 1U Rack
|
h.264 / h.265
|
4 x HDMI or SDI in
3.5mm Stereo in
|
--
|
--
|
|
FBE216-H.264
|
19’ 3U Rack
|
h.264
|
16 x HDMI or SDI in
3.5mm Stereo in
|
--
|
--
|
|
FBE216-H.265
|
19’ 3U Rack
|
h.264 / h.265
|
16 x HDMI or SDI in
3.5mm Stereo in
|
--
|
--
|
