Freescale MRF6V2300NB VHF RF Power Fet. 300w / 50v.

Designed primarily for CW large - signal output and driver applications with frequencies to 600 MHz. Devices are unmatched and are suitable for use in industrial, medical and scientific applications. Typical CW Performance: VDD = 50 Volts, IDQ = 900 mA, Pout = 300 Watts, = 220 MHz Power Gain 25.5 dB Drain Efficiency 68% Capable of Handling 10:1 VSWR, @ 50 Vdc, 220 MHz, 300 Watts CW Output Power Features Integrated ESD Protection Excellent Thermal Stability Facilitates Manual Gain Control, ALC and Modulation Techniques 200°C Capable Plastic Package RoHS Compliant In Tape and Reel. R1 Suffix = 500 Units per 44 mm, 13 inch Reel.

- 600 MHz, 50 V LATERAL N - CHANNEL SINGLE - ENDED BROADBAND RF POWER MOSFETs
CASE - 04, STYLE - 4 PLASTIC MRF6V2300NBR1 PARTS ARE SINGLE - ENDED
(Top View) Note: Exposed backside of the package is the source terminal for the transistor.

Rating Drain- Source Voltage Gate- Source Voltage Storage Temperature Range Case Operating Temperature Operating Junction Temperature Symbol VDSS VGS Tstg TC TJ Value +150 200 Unit Vdc °C

How far(long) the transmitter cover?

The transmission range depends on many factors. The true distance is based on the antenna installing height , antenna gain, using environment like building and other obstructions , sensitivity of the receiver, antenna of the receiver . Installing antenna more high and using in the countryside , the distance will much more far.

EXAMPLE 5W FM Transmitter use in the city and hometown:

I have a USA customer use 5W fm transmitter with GP antenna in his hometown ,and he test it with a car, it cover 10km(6.21mile).

I test the 5W fm transmitter with GP antenna in my hometown ,it cover about 2km(1.24mile).

I test the 5W fm transmitter with GP antenna in Guangzhou city ,it cover about only 300meter(984ft).

Below are the approximate range of different power FM Transmitters. ( The range is diameter )

0.1W ~ 5W FM Transmitter ：100M ~1KM

5W ~15W FM Ttransmitter : 1KM ~ 3KM

15W ~ 80W FM Transmitter : 3KM ~10KM

80W ~500W FM Transmitter : 10KM ~30KM

500W ~1000W FM Transmitter : 30KM ~ 50KM

1KW ~ 2KW FM Transmitter : 50KM ~100KM

2KW ~5KW FM Transmitter : 100KM ~150KM

5KW ~10KW FM Transmitter : 150KM ~200KM
