FMUSER FBE200 H.264 H.265 High Definition HD IPTV Streaming Encoder -fmuser encoder

Total:158 USD
Item:158 USD   Shipping:0 USD

FMUSER H.264 High Definition HD IPTV Streaming Encoder -FBE200-H.264-LAN

Features

--Video Compression support H.264,Main Profile / High Profile / Baseline Profile
--Audio Compression support MP3 & AAC-LC/HE audio compression
--Bitrate CBR / VBR16Kbit/s--12Mbit/s
--Streaming resolution up to 720, 720P, 1080P
--GOP frame rate settings supported
--insertable of logo and Scroll Caption(OSD)
--Adjustable of audio gain
--Capable of image parameter settings
--Support up to 3 stream at a same time
--Switchable of audio output mode: Left, right and Stereo
--Configurable of Multi-rate, Multi-resolution, Multi-protocol
--Providing HLS / RTSP / HTTP / UDP / RTMP protocol
--Support  ffmpeg , HLS
--Support ONVIF Network Video Protocol
--Web-based management
--Full-duplex mode 1000M / 100M
--Multiple output streams per input service to support Broadcast, VOD, IPTV and OTT, Mobile/ web, Set top box applications
--Support multiple equipments display at the same time on one computer
--Support Microsoft standard flow driven architecture (WDM architecture), support Microsoft WMENCODER, compatible with Windows VFW software architecture and WDM mode.

Applications

--Digital TV Broadcasting System
--RJ45 Digital TV Programs Transmission
--Hotel TV System
--Head-end system of Digital TV branch network
--CATV Broadcasting system
--Edge side of Digital TV backbone network
--IPTV and OTT headend system
--Digital Signage
--Video Conference
--Replace HD Video Capture Card
--Hotel TV system
--Streaming Live Broadcast
--Teaching/Campus Broadcast
--Recording System

--NVR,Net Video Recorder

FMUSER FBE200 support a secure live and on-demand streaming both within and outside their corporate networks. Empowers enterprises to personalize engagement, reduce travel costs, extend their reach, and boost sales through video streaming.

Broadcast Streaming Solutions, Powering Leading-Edge Broadcasting.

Schematic diagram

Technical Specifications:

*VIDEO Encoding

--Video Compression: H.264 / AVC / HEVC High Profile Level 1.5
--Video Inputs: 1 x HDMI 1.3a version (support HDCP protocol, or 1 x SDI for option)
--Resolution:
-----HDMI / SDI main stream:
1920x1080, 1680x1056, 1280x720, 1024x576, 850x480, 720x576, 720x540, 720x480,
720x404, 704x576, 640x480, 640x360, auto
-----HDMI / SDI sub-stream:
1280x720, 800x450, 720x576, 720x540, 720x480, 720x404, 704x576, 640x480,
640x300, 352x288, 320x240, 320x180, auto
--Bit-rate: 16kbps~12Mbps, CBR/VBR

--Video pre-processing: Noise reduction, Sharpen, Filtering

*AUDIO Encoding
--Audio compression: AAC, MP3
--Sampling rate: Adaptive, selectable of re-sample.
--Sampling accuracy: 24-bit
--Bit Rate: 48k,64k,96k,128k,160k,192k,256k
--Re-sample:32k, 44.1k

*IP Encapsulation output

--Transport protocol: TS over IP output, RTSP / HTTP / UDP or RTMP protocol
--For each HDMI (SDI) to IP output (HTTP / RTSP / UDP / RTMP / HLS protocol) 3 group out with higher resolution(up to 1080P) for large screen application.
--Output : RJ45, 100/1000M Full


*GENERAL OPTION
--Power supply Voltage: 110VAC±10%, 50/60Hz; 220VAC±10%, 50/60Hz
--DC Power input: 12V or 5V by Micro-USB
--Consumption: less than 40W
--Operating temperature: 0--45°C (operation), -20--80°C (storage)
--Dimensions: 146mm(W)x140mm(D)x27mm(H)
--Package Dimensions: 165mm(W)x112mm(D)x70mm(H)

--Package Weight: 0.65KG

Appearance and Illustration

Front Panel:

1. RJ45 100M / 1000M IP Output
2. 3.5mm Stereo Audio Line in
3. HDMI Video in
4. Status LED / Power LED
5. Reset to Factory

Rear Panel:

1. 2.4G Wifi Antenna Port--SMA-K
2. Micro-USB power in 5V

3. DC Power in 12V

Network Management System

Network management system is applied to control and manage parameters and setting, etc. It centralizes encoders through network easy.

Packing List:

1pcs  FBE200    IPTV streaming encoder HDMI in
1pcs                  HDMI Cable
1pcs                 3.5mm to RCA female (L-R)
1pcs                110V / 220V to 12V Power supply
1pcs                User Manual

Order Guide

Total:158 USD
Item:158 USD   Shipping:0 USD







How far(long) the transmitter cover? The transmission range depends on many factors. The true distance is based on the antenna installing height , antenna gain, using environment like building and other obstructions , sensitivity of the receiver, antenna of the receiver . Installing antenna more high and using in the countryside , the distance will much more far. EXAMPLE 5W FM Transmitter use in the city and hometown: I have a USA customer use 5W fm transmitter with GP antenna in his hometown ,and he test it with a car, it cover 10km(6.21mile). I test the 5W fm transmitter with GP antenna in my hometown ,it cover about 2km(1.24mile). I test the 5W fm transmitter with GP antenna in Guangzhou city ,it cover about only 300meter(984ft). Below are the approximate range of different power FM Transmitters. ( The range is diameter ) 0.1W ~ 5W FM Transmitter ：100M ~1KM 5W ~15W FM Ttransmitter : 1KM ~ 3KM 15W ~ 80W FM Transmitter : 3KM ~10KM 80W ~500W FM Transmitter : 10KM ~30KM 500W ~1000W FM Transmitter : 30KM ~ 50KM 1KW ~ 2KW FM Transmitter : 50KM ~100KM 2KW ~5KW FM Transmitter : 100KM ~150KM 5KW ~10KW FM Transmitter : 150KM ~200KM How to contact us for the transmitter? Call me +8618078869184 OR Email me [email protected] 1.How far you want to cover in diameter ? 2.How tall of you tower ? 3.Where are you from ? And we will give you more professional advice. About Us FMUSER.ORG is a system integration company focusing on RF wireless transmission / studio video audio equipment / streaming and data processing .We are providing everything from advice and consultancy through rack integration to installation, commissioning and training.   We offer FM Transmitter, Analog TV Transmitter, Digital TV transmitter, VHF UHF Transmitter, Antennas, Coaxial Cable Connectors, STL, On Air Processing, Broadcast Products for the Studio, RF Signal Monitoring, RDS Encoders, Audio Processors and Remote Site Control Units, IPTV Products, Video / Audio Encoder / Decoder, designed to meet the needs of both large international broadcast networks and small private stations alike.   Our solution has FM Radio Station / Analog TV Station / Digital TV Station / Audio Video Studio Equipment / Studio Transmitter Link / Transmitter Telemetry System / Hotel TV System / IPTV Live Broadcasting / Streaming Live Broadcast / Video Conference / CATV Broadcasting system.   We are using advanced technology products for all the systems, because we know the high reliability and high performance are so important for the system and solution . At the same time we also have to make sure our products system with a very reasonable price.   We have customers of public and commercial broadcasters, telecom operators and regulation authorities , and we also offer solution and products to many hundreds of smaller, local and community broadcasters .   FMUSER.ORG has been exporting more than 15 years and have clients all over the world. With 13 years experience in this field ,we have a professional team to solve customer's all kinds of problems. We dedicated in supplying the extremely reasonable pricing of professional products & services. Contact email : [email protected] Our Factory We have modernization of the factory . You are welcome to visit our factory when you come to China. At present , there are already 1095 customers around the world visited our Guangzhou Tianhe office . If you come to China , you are welcome to visit us . At Fair This is our participation in 2012 Global Sources Hong Kong Electronics Fair . Customers from all over the world finally have a chance to get together. Where is Fmuser ? You can search this numbers " 23.127460034623816,113.33224654197693 " in google map , then you can find our fmuser office . FMUSER Guangzhou office is in Tianhe District which is the center of the Canton . Very near to the Canton Fair , guangzhou railway station, xiaobei road and dashatou , only need 10 minutes if take TAXI . Welcome friends around the world to visit and negotiate . Contact: Sky Blue Cellphone: +8618078869184 WhatsApp: +8618078869184 Wechat: +8618078869184 E-mail: [email protected] QQ: 727926717 Skype: sky198710021 Address: No.305 Room HuiLan Building No.273 Huanpu Road Guangzhou China Zip:510620 English: We accept all payments , such as PayPal, Credit Card, Western Union, Alipay, Money Bookers, T/T, LC, DP, DA, OA, Payoneer, If you have any question , please contact me [email protected] or WhatsApp +8618078869184 PayPal.  www.paypal.com We recommend you use Paypal to buy our items ,The Paypal is a secure way to buy on internet . Every of our item list page bottom on top have a paypal logo to pay. Credit Card.If you do not have paypal,but you have credit card,you also can click the Yellow PayPal button to pay with your credit card. --------------------------------------------------------------------- But if you have not a credit card and not have a paypal account or difficult to got a paypal accout ,You can use the following: Western Union.  www.westernunion.com   Pay by Western Union to me : First name/Given name: Yingfeng Last name/Surname/ Family name: Zhang Full name: Yingfeng Zhang Country: China City: Guangzhou  --------------------------------------------------------------------- T/T .  Pay by T/T (wire transfer/ Telegraphic Transfer/ Bank Transfer)  First BANK INFORMATION (COMPANY ACCOUNT): SWIFT BIC: BKCHHKHHXXX Bank name: BANK OF CHINA (HONG KONG) LIMITED, HONG KONG Bank Address: BANK OF CHINA TOWER, 1 GARDEN ROAD, CENTRAL, HONG KONG BANK CODE: 012 Account Name : FMUSER INTERNATIONAL GROUP LIMITED Account NO. : 012-676-2-007855-0 --------------------------------------------------------------------- Second BANK INFORMATION (COMPANY ACCOUNT): Beneficiary: Fmuser International Group Inc Account Number: 44050158090900000337 Beneficiary's Bank: China Construction Bank Guangdong Branch SWIFT Code: PCBCCNBJGDX Address: NO.553 Tianhe Road, Guangzhou, Guangdong,Tianhe District, China **Note: When you transfer money to our bank account, please DO NOT write anything in the remark area, otherwise we won't be able to receive the payment due to government policy on international trade business. * It will be sent in 1-2 working days when payment clear. * We will send it to your paypal address. If you want to change address, please send your correct address and phone number to my email [email protected] * If the packages is below 2kg,we will be shipped via post airmail, it will take about 15-25days to your hand. If the package is more than 2kg,we will ship via EMS , DHL , UPS, Fedex fast express delivery,it will take about 7~15days to your hand. If the package more than 100kg , we will send via DHL or air freight. It will take about 3~7days to your hand. All the packages are form China guangzhou. * Package will be sent as a "gift" and declear as less as possible,buyer don't need to pay for "TAX". * After ship, we will send you an E-mail and give you the tracking number. For Warranty . Contact US--->>Return the item to us--->>Receive and send another replace . Name: Liu xiaoxia Address: 305Fang HuiLanGe HuangPuDaDaoXi 273Hao TianHeQu Guangzhou China. ZIP:510620 Phone: +8618078869184 Please return to this address and write your paypal address,name,problem on note:
