FMUSER 5KW Rack FM Transmitter

Innovative FMUSER FM broadcast transmitter for radio stations,hot-plug amplifier module and double digital exciters,automatically change.Output power is stable with AGC fuction.

This 5KW FM transmitter is an excellent FM stereo transmitter for professional radio station.It is reliable and high performance.It consists of center control module,double digital exciters,6 pcs hot-plug 1KW FM amplifer modules,6-way combiner,a perfect BPF and 5 pcs hotplug 2500VA switched power source modules.

1. Six units 1KW hotplug RF power modules.Total output power is extremely stable thanks to AGC(Automatic Gain Control).

2. Five units 2500VA hotplug switched power supply units are working in parallel.

4. Two All-digital 10W exciters(DSP+DDS) with automatical changeover switch.

6. 8-inch Color LCD with touch panel displys all the parameters in real time.

7. Intelligent protect fucntions by centre control unit,like over Pf,over SWR,over Temp,Over V,Over I.

8. Real hot-plug structure,the modules can be repairing at non-stop condition.

Technical Specifications:
1.   Frequency Range:                                   87.0MHz~108 MHz
2.   Frequency Setting step:                           10KHz
3.   Carrier Frequency precision:                   200Hz
4.   Residual Wave Radiation:                       70dBc
5.   Analog audio Input Impedance:               600Ω, Balance
    AES/EBU digital audio input impedance: 110 Ohm, Balance
6.   Separation:                                             >50dB,30Hz~15KHz
7.   Audio Input Level:                                  -10dBm~+10dBm, step 0.01dB
8.   S/N:                                                       >75dB (1kHz, 100%modulation)
9.   Audio Harmonic Distortion:                     <0.1%
10. Audio response:                                      0.1dB(10Hz~15KHz)
11. Output Load Impedance:                         50Ω
12. Output Power:                                        0W~5KW
13. Pre-emphasis:                                         0μS, 50μS, 75μS
14. Deviation:                                               ±75kHz
15. Pilot Frequency:                                      19 kHz; 0.5Hz
16. RF Output Interface:                               1+5/8'
17.Size:                                                        Width(72mm),Height(1950mm),Depth(1200mm)
18.Weight:                                                    350KG

How far(long) the transmitter cover?

The transmission range depends on many factors. The true distance is based on the antenna installing height , antenna gain, using environment like building and other obstructions , sensitivity of the receiver, antenna of the receiver . Installing antenna more high and using in the countryside , the distance will much more far.

EXAMPLE 5W FM Transmitter use in the city and hometown:

I have a USA customer use 5W fm transmitter with GP antenna in his hometown ,and he test it with a car, it cover 10km(6.21mile).

I test the 5W fm transmitter with GP antenna in my hometown ,it cover about 2km(1.24mile).

I test the 5W fm transmitter with GP antenna in Guangzhou city ,it cover about only 300meter(984ft).

Below are the approximate range of different power FM Transmitters. ( The range is diameter )

0.1W ~ 5W FM Transmitter ：100M ~1KM

5W ~15W FM Ttransmitter : 1KM ~ 3KM

15W ~ 80W FM Transmitter : 3KM ~10KM

80W ~500W FM Transmitter : 10KM ~30KM

500W ~1000W FM Transmitter : 30KM ~ 50KM

1KW ~ 2KW FM Transmitter : 50KM ~100KM

2KW ~5KW FM Transmitter : 100KM ~150KM

5KW ~10KW FM Transmitter : 150KM ~200KM
